The 4CH Bluetooth Dante Panel (BT44) is a versatile signal conversion and transmission panel that offers a multitude of connectivity options. It supports a Dante audio interface with 4x4 channels, a Bluetooth audio interface with 2x2 channels, and an analog audio interface in either RCA or TRS format.
The 4CH Bluetooth Dante Panel Designed for wall mounting and powered by PoE (Power over Ethernet), this panel simplifies audio transmission and power supply by utilizing a single network cable. This not only reduces cable clutter but also enhances the overall neatness and efficiency of the audio setup.
In addition to its robust connectivity options, the 4CH Bluetooth Dante Panel is ideal for a wide range of applications, including telephone conferences and audio remote transmission. Its ability to support both Bluetooth wireless audio and analog audio interfaces makes it a highly adaptable solution for various audio needs.
Overall, the 4CH Bluetooth Dante Panel (BT44) is a powerful and flexible audio transmission panel that offers a seamless blend of modern connectivity options and traditional audio interfaces. Its compact design and PoE power supply make it an excellent choice for a variety of audio transmission scenarios.
|
Model No. |
BT44 |
|
Products Name |
4CH Bluetooth Dante Panel |
|
Input Interface |
Dante X 4 Bluetooth 5.0, stereo RCA X2 3.5 mm TRS X1 |
|
Output interface |
Dante X4 Bluetooth 5.0, stereo 3.5 mm TRS X 1 |
|
Frequency response |
20Hz-20kHz |
|
S/N |
>100dB |
|
Floornoise |
-90dB |
|
Power consumption |
2W |
|
THD (total harmonic distortion) |
<0.005% |
|
Operating temperature |
-10℃~+40℃ |
|
Operating humidity |
5~95% |
|
Size(LxWxH) |
123.5mm×109.1mm×30mm |
|
Weight |
310g |
The 4CH Bluetooth Dante Panel (BT44) boasts an impressive array of features designed to enhance audio transmission and connectivity:
• Simple Pairing: The panel offers easy Bluetooth pairing, with an LED indicator displaying the connection status at a glance.
• Excellent Compatibility: The BT44 is compatible with a wide range of devices, including mobile phones, tablets, and computers, ensuring seamless integration into any audio setup.
• Versatile Audio Inputs: The panel provides two RCA inputs and one 3.5mm TRS input for stereo audio. Users can choose between the two inputs, with the TRS input having priority.
• Stereo Output: A 3.5mm TRS output is available for stereo audio playback.
• Advanced Bluetooth Technology: Equipped with BT 5.0, the panel offers faster and more stable Bluetooth connections.
• Dante Interface: The Dante 4x4 interface supports high-quality audio transmission over Ethernet, making it ideal for professional audio applications.
• Integrated Power Supply and Transmission: The panel integrates power supply and audio transmission, utilizing PoE (Power over Ethernet) technology to provide power and transmit audio through a single network cable.
• Bluetooth Call Bridge Function: The BT44 features a Bluetooth call bridge function, allowing it to be used as a conference bridge for seamless audio communication.
• Customizable Bluetooth Name: Users can modify the Bluetooth name of the panel for easier identification and connection.
The 4CH Bluetooth Dante Panel (BT44) has a wide range of application scenarios due to its versatile features and high compatibility. Here are some typical use cases:
1. Conference Rooms and Meeting Spaces:
The BT44 can be used to facilitate seamless audio communication during telephone conferences or video meetings.
Its Bluetooth call bridge function allows for easy integration with mobile phones or other Bluetooth-enabled devices, enabling participants to join the conference call wirelessly.
o The Dante interface supports high-quality audio transmission, ensuring clear and crisp sound quality during meetings.
2. Educational Institutions:
o Schools and universities can use the BT44 to set up wireless audio systems in classrooms or lecture halls.
o Teachers can easily connect their mobile devices or laptops to the panel to play audio content or conduct interactive sessions.
o The panel's compatibility with a wide range of devices makes it suitable for both teachers and students.
3. Live Events and Performances:
o The BT44 can be used to transmit audio signals wirelessly from performers to a sound system.
o It supports both analog and digital audio interfaces, allowing for flexible connectivity options.
o The panel's high-quality audio transmission capabilities ensure that the sound is clear and distortion-free during live performances.
4. Corporate Offices:
o Businesses can use the BT44 to create a versatile audio communication system within their offices.
o Employees can connect their devices to the panel to share audio content during meetings or presentations.
o The panel's compact design and wall-mounting capabilities make it easy to integrate into any office environment.
5. Home Audio Systems:
o The BT44 can be used to upgrade home audio systems by adding wireless connectivity options.
o Users can connect their smartphones, tablets, or other Bluetooth-enabled devices to the panel to stream music wirelessly.
o The panel's high-quality audio transmission ensures that music sounds great through any connected speakers or headphones.
