The 4CH 750W Dante DSP Amplifier integrates a 3.97-inch color TFT touch screen module and an audio processing unit. It has four analog audio balanced signal inputs, and is processed through a series of software-based digital technologies and finally converted into four balanced outputs. The amplifier is equipped with proprietary control software that supports dual interface operations: a Windows computer version and a version that runs directly on the amplifier touch screen. Users can synchronize the two interfaces through the touch screen, Dante network protocol or USB connection.
|
Model No. |
D4750 |
|
8Ω Stereo Power |
4x750W |
|
Level adjustment |
Front panel potentiometer, from -infinity to 0dB |
|
Frequency response |
20 - 20kHz, ±0.3dB |
|
Maximum input level |
+14 dBu, balanced input |
|
Maximum output level |
+14 dBu, balanced output |
|
THD+N |
<0.008% @ 2.2 dBu |
|
Sampling rate |
48KHz |
|
Quantization bit number |
24bit |
|
Noise floor |
-88dBu |
|
Input impedance |
20 KΩ (balanced input), 10 KΩ (unbalanced input) |
|
Output impedance |
100 Ω (balanced output), 50Ω (unbalanced output) |
|
Input sensitivity |
1.22V |
|
Input common mode rejection ratio |
>80dB |
|
Output connector |
STeakon socket |
|
USB interface |
Parameter control through TC software operation |
|
Network connection input socket |
Connect the amplifier to the network to achieve remote parameter adjustment |
|
Network connection output socket |
Connect to the network input socket of the next amplifier to achieve online operation of multiple amplifiers |
|
Signal-to-noise ratio |
>112dB |
|
Damping coefficient |
> 1000@ 8Ω |
|
Total harmonic distortion |
<0.1% (20Hz-20 kHz 1W) |
|
Frequency response |
20Hz-34KHz (+0/-0.3dB, 1W/8Ω) |
|
Cooling method |
Stepless speed adjustment fan, airflow from front to back |
|
Amplifier protection method |
Short circuit, open circuit, DC voltage, overheating, overvoltage, radio frequency, ultra-low frequency protection |
|
Power supply specification |
AC voltage 180-240VC (90V-120VAC) 50-60Hz |
|
Chassis size (height*width*length) |
88mmX490mmX438mm |
|
Packaging size (height*width*length) |
155mmX600mm×550mm |
|
Net weight |
13.5kg |
|
Gross weight |
16.5kg |
1. 4CH 750W Dante DSP Amplifier with high-performance ADI DST processor ensures high-fidelity, low-noise 24-bit A/D and D/A conversion.
2. An embedded Dante network transmission module is installed, supporting 4-channel Dante and 4-channel analog signal inputs, with 4 sets of digital power amplifier outputs available.
3. USB and RJ45 interfaces are provided for connection to computers.
4. Each output channel boasts 8-band parametric equalization, frequency division, delay, limiter, gain, and polarity settings for customized audio output.
5. A high-efficiency, high-power-density Class D amplifier is used, equipped with excellent protection functions such as overcurrent, overheating, and high-frequency protection.
6. A 3.97-inch touchscreen with both Chinese and English menus offers intuitive and comprehensive operation and display.
Imagine that in a place that requires high-quality audio output, such as a large conference room or performance venue, the 4CH 750W Dante DSP Amplifier is undoubtedly an ideal choice. It provides four channels of 750 watts of powerful power to ensure that each speaker can get sufficient power supply. At the same time, through the Dante network, audio signals can be easily transmitted between various devices without complicated wiring. The built-in DSP function adds unlimited possibilities to the audio effects, whether it is to enhance the bass effect or adjust the balance of the sound, it can be easily achieved.
