Our team of experts is dedicated to providing you with excellent customer service and support, ensuring that your experience with us is seamless and satisfactory. We sincerely look forward to the opportunity to cooperate with you and discuss how our 16 Channel Digital Audio Matrix can meet your specific requirements. Your satisfaction is our top priority, and we are confident that you will find our product to be an excellent addition to your audio setup.
|
Model No. |
MX-1616 |
|
Main Specification |
|
|
DSP Chip |
Ti 456MHz FLOPS Dual-core |
|
USB2.0 recording/playback |
Support |
|
Central Control Instruction Set Generator |
Support |
|
Input Processing |
Pre-amplification, signal generator, expander, compressor, 5-band parametric equalization, automatic gain, AM automatic mixing function, AFS,AEC,ANC |
|
Output Processing |
Speaker manager (31-band graphic equalizer, delay, crossover, limiter, high and low channel filters) |
|
Matrix mixing |
Input and output signal matrix mixing, mixing component control |
|
Automatic camera tracking function |
Support |
|
Scene preset |
100 groups of custom settings |
|
Port configuration |
|
|
Analog input channel |
16 |
|
Analog output channel |
16 |
|
Ethernet control port |
1 |
|
RS232、RS485 |
RS232：1；RS485:1 |
|
GPIO |
8 |
|
Front stage gain |
51dB(each level 3dB，total 17 level) |
|
Balanced/unbalanced, input/output support |
Support |
|
MIC\LINE, input/output support |
Support |
|
Independent 48V phantom power switch for each channel |
Support |
|
DSP Processing |
|
|
AM、AGC、AFS、AEC |
√ |
|
Specification |
|
|
Sampling Rate |
48k@24bit |
|
Phantom power |
48V |
|
Frequency response |
20Hz～20K Hz，±0.3dB |
|
THD+N |
≤0.005% @1k，4dBu |
|
Working power |
AC110V-220V,50Hz/60Hz |
|
Noise floor |
-90dBu |
|
Size |
482*258*45(mm) |
Q: What is a 16 Channel Digital Audio Matrix?
A: It is a device that allows for the routing and mixing of 16 audio channels in a digital format, enabling flexible audio distribution and control.
Q: How many audio channels can a 16 Channel Digital Audio Matrix handle?
A: It can handle up to 16 audio channels simultaneously.
Q: Is the 16 Channel Digital Audio Matrix compatible with all audio formats?
A: It is compatible with a wide range of digital audio formats, but it's always best to check the specific compatibility of your chosen model.
Q: Can I use the 16 Channel Digital Audio Matrix for both input and output routing?
A: Yes, it typically supports both input and output routing, allowing for complex audio setups.
Q: How do I control the routing and mixing in a 16 Channel Digital Audio Matrix?
A: Control can be achieved through software interfaces, touchscreens, or physical control panels, depending on the model.
Q: Is the 16 Channel Digital Audio Matrix suitable for live events?
A: Absolutely, it's often used in live sound environments due to its flexibility and reliability.
